Expand your application range with triple-channel detection. Light Sources - Blue LED (max ~480 nm) - Red LED (max ~630 nm) - Green LED (max ~535 nm)
EzCube fluorometer works with EzQuant quantification assays and other commonly used options. - 1X dsDNA HS (High-Sensitivity) - ssDNA - RNA HS (High-Sensitivity)
196 mm x 248 mm x 68 mm 1KG
The EzCube Fluorometer features triple fluorescent channels and offers high-sensitivity and specific quantification of nucleic acids and proteins. It accurately measures low concentration samples as small as 1µL, making it ideal for demanding applications, including NGS. Combined with dedicated EzQuant quantification assays, an intuitive touchscreen and Wi-Fi connectivity, EzCube simplifies your precision quantification processes and makes them easy.
1、Enhanced accuracy and sensitivity: quantify low concentrations of DNA, RNA and protein with just 1µL in seconds, more sensitive than UV absorbance measurements
2、3 fluorescent channels: expand your application range with triple-channel detection (blue, red and green)
Easy operation: seamlessly control your workflow with an intuitive 7-inch touchscreen and a built-in reagent calculator
3、Flexible data management: easily export your data via USB or Wi-Fi in a quick and easy way
4、High compatibility with quantification assays: EzCube fluorometer works with EzQuant quantification assays and other commonly used options
Features Highlights
Enhanced Accuracy and Sensitivity
Quantify low concentrations of DNA, RNA and protein with just 1 µl in seconds, more sensitive than UV absorbance measurements.
Three Fluoresent Channels
Expand your application range with triple-channel detection.
Easy Operation
Seamlessly control your workflow with an intuitive 7-inch touchscreen and a built-in reagent calculator.
Flexible Data Management
USB connectivity for easy data export.
High Compatibility with Quantification Assays
EzCube fluorometer works with EzQuant quantification assays and other commonly used options.
Specifications
Dynamic Range | 5 orders of magnitude |
Light Sources | Blue LED (max ~480 nm) Red LED (max ~630 nm) Green LED (max ~535 nm) |
Excitation Filters | Blue (430 - 495 nm) Red (600 - 645 nm) Green (490 - 535 nm) |
Emission Filters | Blue (510 - 580 nm) Red (665 - 720 nm) |
Detectors | Photodiodes; measurement capability from 320 -1,100 nm |
Tube Type | 0.5 ml polypropylene thin wall PCR tubes |
Operating System | Custom Linux based OS |
Display | 7” touch screen, 1,280*800 TFT-LCD |
Connectivity | USB-A port x2 (Data output) |
Dimensions (W x D x H) Weight | 196 mm x 248 mm x 68 mm (7.7 x 9.8 x 3.4 in.) 1 kg (2.2 lb.) |
