Display size: 8.4'' color TFT
More than 60 samples per hour, operatable 24 hours a day, auto sleeping and waking-up functions
33CM(L)*38CM(W)*43CM(H) 12KG
3-part differentiation of WBC, 23 parameters, double channel counter, up to 60 samples per hour
Volume measurement by time, not wrong warning
Advanced valve technology, long life
Electrical resistance for counting and SFT method of Hemaglobin
Low sample consumption: venous 9.8 ul, prediluted 20 ul for twice testing one time
8.4” color TFT, Windows interface all testing parameters displayed simultaneously
Windows operation system graphical buttons mouse and keyboard operation
Automatic diluting, Mixing, rinsing and clog clearing
Automatically sample probe cleaning (inside and outside)
Large storage capacity: up to 10,000 samples +3 histograms
Internal thermal-sensitive printer or external printer.
RS232 interface, PC connecting
TECHNICAL DATA
Specification: Parameter: 3-part differentiation of WBC; 20 parameters and 3 color histograms (WBC, RBC, PLT)
Specification: Throughput: More than 60 samples per hour, operatable 24 hours a day, auto sleeping and waking-up functions
Specification: Methodology: Electrical resistance for counting, hemiglobin cyanide method and SFT method for hemoglobin
Specification: Sample volume: 9.8µL for Venous and capillary mode, 20 µL for prediluted mode
Specification: Work mode : Double Channel + unique Hemoglobin test system
Specification: Storage: up to 100000 sample results including histograms can be stored, convenient for inquiry and management of history data
Specification: Display size: 8.4'' color TFT
Specification: Print: Graphic thermal printer with various printing format,optional external printer
Specification: Dimensions: 33CM(L)*38CM(W)*43CM(H)
