roductivity – 60 tests / hour; The duration of the measuring cycle is 60 s;
Twenty parameters in both PD and WB mode. The hourly throughput of the Sysmex XP 300 is approximately 60 samples
1 year
Sysmex XP 300 is a reliable hematology analyzer suitable for any clinical setup requiring robust and high-quality diagnostic results. XP 300 comes with a wide range of new specifications, such as an effective reagent management system, touch screen, etc
Sysmex XP 300 is the 3-part differential automated hematology analyzer that combines the robustness and confidence in the results of its predecessor, the KX-21N, with a modern design and new features such as Spanish-language software with intuitive menus, a touch screen, and a barcode reagent management system that will optimize the laboratory routine.
The XP 300 performs a separate count of neutrophils and lymphocytes, which compares favorably with other 3-DIFF analyzers, where neutrophils are included in the calculation of the total group of granulocytes and are not read separately.
The possibility of separate counting of neutrophils and lymphocytes on the XP-300 analyzer is of great clinical importance: an increased number of NEUT neutrophils (#,%) is important for assessing the acute phase of inflammatory and infectious processes and serves as an early marker of the disease. The number of LYMPH lymphocytes (#,%) increases with viral infections and lymphomas.
Specification at a Glance:
Twenty parameters in both PD and WB mode.
The hourly throughput of the Sysmex XP 300 is approximately 60 samples.
The sample volume of whole blood mode is around 50µL, while it is 20µL for pre-diluted mode.
Hand-held barcode reader.
Easy access to QC results.
It comes with a built-in thermal printer.
Color LCD touch screen.
Up to 40000 samples of data storage.
Performance and service:
Productivity – 60 tests / hour;
The duration of the measuring cycle is 60 s;
The minimum amount of reagents is only 2 (3 with Cellclean!) Reagents for 20 parameters: Cellpack (shelf life 18 months, open pack 60 days; Stromatolyser-WH (shelf life 12 months, open pack 90 days);
Number of flushing fluids – 1 (Cellclean);
Reagents made in Germany;
The need to calibrate the device only for hemoglobin and hematocrit;
Direct measurement of hematocrit by the accumulation of erythrocyte column volume;
Automatic self-monitoring, flushing, cleaning, and shutdown system;
The ceramic rotary valve of the dispensing system ensures the reliability of the system;
Automatic clot removal, automatic electrical and liquid aperture cleaning;
Built-in quality control with graphing
| Main Components: | XP-300 Complete. Handheld BR Gryphon. Cable CAB-320 |
| Manufacturers & Country of Origin | SYSMEX (Japan/Germany). |
| Optional Components: | Gryphon Retail Stand. Gryphon Desk/Wall holder. External Printer. External Printer Cable. |
| Reagents & their storage temperature | Stromatolyser WH (3×500ml) = +1 – +30⁰C Cell Pack (20L) = +1 – +30⁰C Cell Clean (50ml) = +1 – +30⁰C |
| Controls & calibrators & their storage temperature: | Control = EIGHTCHECK-3WP L; EIGHTCHECK-3WP N; EIGHTCHECK-3WP H – (+2 – +8⁰C) Calibrator = SCS-1000 Calibrator (+2 – +8⁰C) |
| Parameters: | 20 parameters WBC, RBC, HGB, HCT, MCV, MCH, MCHC, PLT, LYM% (W-SCR), MXD% (W-MCR), NEUT% (WLCR), LYM# (W-SCC), MXD# (WMCC), NEUT# (W-LCC), RDW-SD, RDW-CV, PDW, MPV, P-LCR, PCT |
| Technology | DC detection method (WBC, RBC/PLT) non-cyanide haemoglobin detection method (HGB) |
| Profiles/sample type: | Whole blood mode. Pre-diluted mode. |
| Throughput: | 60 Samples/hour. |
Sampling Volume | Approx. 50 μL (whole blood mode) Approx. 20 μL (pre-diluted mode) |
