Gene expression analysis Genotyping Cloning Pathogen detection Food and veterinary testing
41Kg
1–200 µl
Robotic workstation for automated PCR setup (with UV light and HEPA filter), comes with QIAgility software; includes installation, application training and one-year warranty on labor, travel and parts. Does not include a laptop.
QIAGEN QIAgility is intended for molecular biology applications neither intended for the diagnosis, prevention, or treatment of disease nor has it been validated for such use either alone or in combination with other products.
Description
QIAGEN QIAgility is a compact benchtop instrument that enables rapid, high-precision PCR experiments with ready-to-use software for ease and convenience. The software provides step-by-step guidance for worktable setup and automatic calculation of all mixes, eliminating the need to program pipetting steps. Just select the kit and cycler, define your targets and start the run. For added flexibility, the QIAgility is operated via a laptop computer.
QIAgility is an automated instrument to establish Polymerase Chain Reaction (PCR) in just 30 minutes. It works conveniently quickly. It also gives you accurate and standardized results thanks to its reliability and reproducibility system, which can eliminate manual pipetting steps and increase productivity most safely, thus allowing you to minimize errors that usually occur when setting up PCR.
During those 30 minutes, QIAgility will give you solutions in genotyping, cloning, detecting pathogens, analyzing gene expression, or even food and veterinary testing. When entering the pipetting stage, this instrument can sense every time the meniscus occurs so that when the liquid is getting condensed, this instrument will soon adapt to its pipetting speed.
QIAGEN QIAgility Features:
Automated PCR setup in all formats.
Convenient, easy-to-use software.
Pre-optimized experiment setup.
Standardized results and increased productivity.
Elimination of manual pipetting steps.
The QIAgility fully automates proven QIAGEN PCR kits for use with various workflows and offers pure pipetting precision, enhanced safety features, and exceptional reliability and reproducibility.
Specifications:
Communications: USB and RS232
Conductive Filtered Tips: 50 µl and 200 µl Conductive Filtered Tips for liquid-level sensing
Consumables (supplied): 10 racks of 50 µl Conductive Filtered Tips (960); 10 racks of 200 µl Conductive Filtered Tips (960); 25 x 5 ml tubes; 100 x 0.2 µl PCR tubes; 3 Tip Disposal Boxes
Dimensions Height: 45 cm (18 in.), instrument lid closed; Height: 86 cm (34 in.), instrument lid open; Width: 54 cm (21 in.); Depth: 63 cm (25 in.), without cables
Electrical: 100–240 V AC, 250 VA, 50–60 Hz
HEPA filter: Preinstalled dual-cartridge 3M Air-Mate HEPA (High-Efficiency Particulate Air) filter system provides positive pressure clean air within the closed hood.
Humidity: Operating humidity: 40–70%
Liquid-level sensing: Minimum detection volume (10 µl in 200 µl PCR tubes). Only functional in combination with QIAGEN Conductive Filtered Tips.
Notebook (supplied): QIAgility comes with a notebook computer for added flexibility.
Pipetting head: Single channel
Place of operation: For indoor use only
Pollution level: 2
Precision: CV <1%, 5–200 µl (dry-well transfer) CV <5%, 2–5 µl (wet-well transfer) CV <10%, 1 µl
Software: Supplied with an unlimited user license. Free upgrades by Web download.
Table capacity: 6 x SBS positions (127.76 x 85.48 mm) for adapters and Tip Rack Holders 1 x Master Mix Block 1x Reagent Block
Temperature: Operating temperature, 15–30 °C (59–86°F)
Tip disposal: All used tips ejected externally — no waste accumulation on the worktable
Tip volume: 1–200 µl
Include:
cables
Qiagen Qiagility instrument
Laptop computer with control software installed (any software licensing is the responsibility of the buyer)
USB and power cables
(1) Reagent Block, 16x 0.2ml / 2ml Flat / 1.5 ml Tapered Tubes mat no 9018951
(1) Master Mix Block, 1x 5ml / 4 x 1.5ml Tubes mat no 9018958
(1) Flip=Cap Tube Lifter 32 x 1.5ml Tapered mat no 9018927
(1) Adapter, 96×0.2ml PCR Tubes
(4) Tip Rack Holder for 96-Tip Rack mat no 9018949
(1) Box Filter-Tips 200ul (96 ct)
(1) Box Filter-Tips 50ul (96 ct)
Reagent Trough Lid for use with the QIAgility (10 x 70 ml)
Reagent Trough Lid for use with the QIAgility (20 x 170 ml)
Reagent Trough Lid for use with the QIAgility (15 x 270 ml)
Graduated, Flat-Base Tubes for use with the QIAgility (50 x 5 ml)
Tip Receptacle Boxes for disposal of used tips from the QIAgility (10)
