Aeonmed Shangrila 510S Portable Ventilator – Advanced Emergency & ICU Ventilation
The Aeonmed Shangrila 510S Portable Ventilator is a state-of-the-art transport ventilator designed for both emergency and ICU settings. Because patient safety is the top priority, this ventilator combines advanced technology with user-friendly operation. As a result, it ensures optimal respiratory support for adults, pediatric patients, and infants.
Key Features That Set It Apart:
Multiple Ventilation Modes: Supports Pressure Control, Volume Control, SIMV, CPAP, and SPONT/PSV, making it suitable for various patient needs.
Broad Patient Compatibility: Since it is designed for adults, children, and infants (above 3.5 kg), it adapts easily to different cases.
Pneumatically Driven, Electronically Controlled: This feature allows for precise airflow regulation while ensuring stable and consistent performance.
Extended Battery Life: Unlike many other ventilators, this model provides up to 10 hours of continuous operation with two batteries.
Real-Time Monitoring & Alarms: The system continuously tracks vital parameters, such as MV, VT, frequency, FiO2, and PEEP, while triggering alarms when necessary.
Compact & Lightweight for Easy Transport: Weighing just 8 kg, this ventilator is highly portable and ideal for ambulances, mobile medical units, and home care settings.
Technical Specifications You Need to Know:
Tidal Volume: 0-2000 ml
Pressure Support: 0-50 cmH2O
Oxygen Concentration: 40-100%
Max Inspiration Flow: 90 L/min
Ventilation Frequency: 1-120 bpm (A/C mode), 1-40 bpm (SIMV mode)
Battery Backup: Up to 10 hours with two batteries
Dimensions: 168mm (H) × 156mm (W) × 300mm (D)
Display: 5-inch TFT LCD screen
Why Choose the Aeonmed Shangrila 510S?
Ideal for Emergency Transport & ICU Use – Whether you are in a hospital or an ambulance, this ventilator provides reliable, uninterrupted respiratory support.
Customizable Ventilation Settings – Because every patient is different, the device offers tailored ventilation options for optimal therapy.
Built for Safety & Efficiency – With intelligent alarms, precise monitoring, and long battery life, you can trust it for critical care situations.
Order the Aeonmed Shangrila 510S Portable Ventilator Today
If you’re looking for a high-performance, reliable transport ventilator, the Aeonmed Shangrila 510S Portable Ventilator is the perfect choice. Not only does it offer exceptional ventilation support, but it also ensures maximum patient comfort. Order now from AdamsMedOnline for fast delivery and professional assistance.
pecifications of Aeonmed Shangrila 510s Transport Ventilator:
Ventilation Mode Assist/Control (A/C) Manual
MV 3~20 L/min (used in 60%)
3~14L/min (used in 100%)
Respiratory rate 10~60bpm
I:E ratio 1:2
FiO2 60%,100%
Trigger sensitivity Pressure, -3cmH2O
Monitoring Pressure values: Paw
Alarm Paw high, O2 supply down
Gas supply O2, 0.28~0.6MPa
Maximum security pressure 8kPa
Compliance 4mL/100Pa
Noise ≤65dB(A)
Dimensions (H×W×D) 276×110×142mm
Weight 2.4kg
Temperature -18°C~50°C (Operation)
-20°C~55°C (Storage)
Relative humidity: 5%~95%, non-condensing (Operation) ≤93% (Storage)
Atmospheric pressure 70~110kPa (Operation)
50~110kPa (Storage)
Features of Aeonmed Shangrila 510s Transport Ventilator:
Classic emergency transport ventilator Pneumatically is driven pneumatically controlled A / C mode with a pressure trigger
High /low-pressure alarm
Oxygen concentration adjustable adult / pediatric parameter in different colors, easy to operate
Simple pipe connection, time-saving compact and portable design
Used in the emergency department, emergency room, country hospital, clinic, and patients inter-departmental transfer.
