High-speed 3D laser scanner with integrated HDR spherical imaging system and Visual Inertial System (VIS) for real time registration
120mm x 240mm x 230mm 5.35 kg
@The Leica RTC360 3D reality capture solution empowers users to document and capture their environments in 3D, improving efficiency and productivity in the field and in the office through fast, simple-to-use, accurate, and portable hardware and software. The RTC360 3D laser scanner is the solution for professionals to manage project complexities with accurate and reliable 3D representations and discover the possibilities of any site.
Fast, agile and precise 3D reality capture solution
FAST
The Leica RTC360 laser scanner makes 3D reality capture faster than ever before. With a measuring rate of up to 2 million points per second and advanced HDR imaging system, the creation of colored 3D point clouds can be completed in under 2 minutes. Plus, automated targetless field registration (based on VIS technology) and the seamless, automated transfer of data from site to office reduce time spent in the field and further maximize productivity.
Agile
Small and lightweight, the Leica RTC360 scanner’s portable design and collapsible tripod mean it’s compact enough to fit into most backpacks, ready to be taken anywhere. Once on-site, easy-to-use one-button operation makes for fast, hassle-free scanning.
Precise
Low noise data allows for better images, resulting in crisp, high-quality scans that are rich in detail and ready for use in a range of applications. Combined with Cyclone FIELD 360 software for automated registration in the field, the Leica RTC360 scanner offers outstanding precision that can be checked on-site.
Kit includes
Leica RTC360 Laser Scanner
Transport Container
GEB361 Lithium-Ion Battery
GKL341 Multichanger Prof 5000
256gb USB Flash Drive
Rain Cover
System USB Card
GST80 Lightweight Tripod
GVP730 Backpack
GAD121 Tribrach Adapter
GAD122 Adapter
RTC360 Quick Guide
1 Year Basic CCP
Includes:
RTC360 Laser Scanner (838300)
RTC360 Transport Container (817063)
GEB361 Lithium-Ion Battery x4 (799191)
GKL341 Multicharger Prof 5000 (799187)
RTC360 USB Flash Drive - 256 GB (842065)
RTC360 Rain Cover (636767)
RTC360 Quick Guide
RTC360 System USB Card
Leica Cyclone FIELD 360
Leica Cyclone REGISTER 360
1 year RTC360 CCP Basic (Customer Care Package)
