B-, B/M-, M-, 2B-, 4B-, CFM-, CPA(PD)-, DPD-, PW-, B/BC-, Triplex-, Quadplex- and Trapezoid Mode
358 mm x 125 mm x 399 mm (L|W|H) 7.8Kg
Gynaecology Urology Paediatrics Radiology Internal medicine
The Chison EBit 30 is a portable multifunctional ultrasound scanner with a high-resolution 15" LCD colour display. It has a variety of imaging modes and can be upgraded with additional software extensions to add more options.
The device can also be used to determine distance, area, circumference, volume and percentages e.g.of stenoses and blood flow velocities.
Using innovative FHI technology, multiple transmission and receiving methods are used during the examination based on the patient's size and weight. This way, high image resolution is maintained even when examining larger or difficult-to-image patients, enabling better diagnostics.
The delivery of the Chison EBit 30 ultrasound scanner includes a C3-E convex probe and a L7-E linear probe. The device has a removable rechargeable battery that can be recharged as needed. When fully charged, it has a running time of two hours.
Product Details
Chison EBit 30
Portable and lightweight ultrasound scanner
Digital Colour Doppler Ultrasound System
Perfect for examining smaller organs such as the thyroid, testicles and chest
Also suitable for examining the brain, heart, vessels and the musculoskeletal system
High-resolution 15-inch LCD colour display
Up to 30° screen rotation function
Measures distance, area, circumference, volume, fetal weight and heartbeat
Measures percentage of stenosis, blood flow velocities, velocity ratios, blood flow volumes and pressure gradients
Automatically measures maximum and minimum velocity values
Measures time interval, pulsatilty index and resistance index
With FHI technology, Q-image and Q-beam
High image resolution by doubling the volume of the received signals
Faster frame rate due to advanced chipset
Features zoom function and depth adjustment
Possible image freezing and storage function
With comment function in the image area on the screen, user-defined commentary terms can be set
Adjustable total gain and contrast
Display of patient ID, time, date, gestation age and estimated delivery date
Individually adjustable frequency track, 8 segment TGC, dynamic range control and perisistence
Includes removable, rechargeable battery with a running time of approx. 2h
System is compatible with Mitsubishi P93W, Sony UP-711MD, Sony UP-X898MD & Mitsubishi CP31W video printers
Features a backlit alphanumeric keypad
Multilingual user interface display, user interface switching, shear plate, and biopsy guided functions
Weight: 7.8 kg
Dimensions: approx. 358 mm x 125 mm x 399 mm (L|W|H)
Optional Dicom 3.0, Super Needle and 2D sheer available separately
Delivery contents: EBit 30 with battery + C3-E convex probe and L7-E linear
Areas of Application
Gynaecology
Urology
Paediatrics
Radiology
Internal medicine
Imaging Modes
B-, B/M-, M-, 2B-, 4B-, CFM-, CPA(PD)-, DPD-, PW-, B/BC-, Triplex-, Quadplex- and Trapezoid Mode
Option: Elastography Mode, Super Needle, Curved Panoramic Imaging, Color M Mode, TDI, Free Steering M Mode, CW Mode, 2D Mode
Connection Options
1 LAN connection
1 S-VIDEO connection
1 VIDEO OUT connection
4 USB ports
2 probe connections
1 Foot Switch connection
1 power-in connection
1 DVI connection
1 VGA connection
1 remote connection
1 ECG connection
